High Temperature Sewing Threads

High-Temperature Sewing Threads are specifically designed to replace various types of synthetic and asbestos sewing threads. These threads are coated with lubricants to improve handling characteristics. GLT Products stocks various Teflon and coated sewing threads that will not burn or support combustion in normal atmospheres. We also stock other high-temperature threads, such as KEVLAR® and CRAQ-SPUN® threads. These high-temp threads are frequently used in removable and reusable insulation blankets for Marine, Aerospace, Industrial and commercial applications. Please consult your sales rep for additional sewing threads that may not be listed here.

Teflon Coated Threads (D-18 and D-24)

  • Suitable temperatures from -400°F to +600°F. They are unaffected by fungi and impervious to alkalis.
  • High strength, uniform PTFE coating
  • Excellent flexibility
  • Chemical resistance

CRAQ-SPUN® Para-Steel Tex 210

  • 8 Strand, 4 Ply
  • 40% para-aramid / 60% stainless steel
  • Max. Temp.: 1200° F
  • Approx. breaking strength: 19 lbs
  • Elongation: 4%
  • Yardage: 2400 yds/LB
  • Approx. Diameter: 0.49 mm
  • Color: Natural (Yellow)/Stainless Steel Blend

Spun Thread Kevlar® Fiber Tex 90

  • Break strength: 17 lbs
  • Elongation: 4.25%
  • Yardage: 4,800 yds/lb
  • Max. Temperature: 800°F (427°C)
  • Max. Continuous Operating Temperature: 300-350°F (148-176° C)
  • Max. Temperature Cold: -50°F (-45 °C)
  • Diameter: 0.013”
  • Denier: 810
  • Cotton count yarn size: 30/5
  • Traverse: 5"
  • Available in Black and Natural (Yellow)

CRAQ-SPUN® Para-Aramid Tex 135

  • 8 Strand, 4 Ply
  • Max. Temp.: 800° F
  • Break Strength: 44 lbs
  • Elongation: Nominal 4%
  • Yardage: Nominal 3300 yds/LB
  • Approx. Diameter: 0.41 mm
  • Color: Natural (Yellow)

SS-304 High-Temperature Thread

  • 10 Stands, .0017" Diameter, 304SS
  • 1000ºF temperature limitation
  • Yield: 6500 linear Feet per pound
  • Break Strenght: 8 Pounds
  • Elongation: 30%

 * All specs are approximate
